Apraksts

• Manufacturer: Texas Instruments
• Product Category: Logic Gates
• RoHS: Details
• Product: Single-Function Gate
• Logic Function: OR
• Logic Family: HCT
• Number of Gates: 3 Gate
• Number of Input Lines: 3 Input
• Number of Output Lines: 1 Output
• High Level Output Current: - 5.2 mA
• Low Level Output Current: 5.2 mA
• Propagation Delay Time: 30 ns
• Supply Voltage - Max: 5.5 V
• Supply Voltage - Min: 4.5 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: SMD/SMT
• Package/Case: PDIP-14
• Packaging: Tube
• Brand: Texas Instruments
• Function: OR
• Height: 4.57 mm
• Input Type: TTL
• Length: 19.3 mm
• Logic Type: 3-Input OR
• Number of Bits: 3 bit
• Operating Supply Current: 20 uA
• Operating Supply Voltage: 5 V
• Operating Temperature Range: - 55 C to + 125 C
• Output Type: CMOS
• Product Type: Logic Gates
• Series: CD74HCT4075
