Apraksts

• Manufacturer: Texas Instruments
• Product Category: Buffers & Line Drivers
• RoHS: Details
• Number of Input Lines: 8 Input
• Number of Output Lines: 8 Output
• Polarity: Non-Inverting
• High Level Output Current: - 6 mA
• Low Level Output Current: 6 mA
• Quiescent Current: 8 uA
• Supply Voltage - Max: 5.5 V
• Supply Voltage - Min: 4.5 V
• Operating Supply Current: 8 mA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Mounting Style: Through Hole
• Package/Case: PDIP-20
• Packaging: Tube
• Brand: Texas Instruments
• Function: Buffer/Line Driver
• Height: 4.57 mm
• Input Signal Type: Single-Ended
• Length: 24.33 mm
• Logic Family: HCT
• Logic Type: CMOS
• Number of Channels: 8
• Operating Supply Voltage: 5 V
• Operating Temperature Range: - 40 C to + 85 C
• Output Type: 3-State
• Product Type: Buffers & Line Drivers
• Propagation Delay Time: 33 ns at 4.5 V, 30 ns at 5.5 V
• Series: SN74HCT541
