Apraksts

• Manufacturer SUNON
• Type of fan DC
• Kind of fan axial
• Supply voltage 12V DC
• Fan dimensions 35x35x10mm
• Power consumption 0.42W
• Current rating 0.035A
• Fan efficiency 10.99m3/h
• Noise level 21.8dBA
• Kind of Bearing Vapo
• Rotational rate/speed 7500rpm
• Weight 10.5g
• Min. insulation resistance 10MΩ
• Impeller material thermoplastic
• Enclosure material thermoplastic
• Insulation class A
• Leads 2 leads
• Operating temperature -10...70°C
• Cable length 140mm
• Fan motor brushless DC motor
• Flammability rating UL94V-0
• Static pressure 3.3mm H2O
• Additional functions Autorestart
• Operating voltage 6...13.8V
• Wire size 28AWG Additional information
• Gross weight: 9.55 g
• Manufacturer part number: MF35101V2-1000U-A99

Parametri

35x35x10mm
12VDC
uz ass
MagLev
10.99m3/st
21.8dBA
7500apgr.
0.42W

Papildu dokumentācija
