Apraksts

• Manufacturer SUNON
• Type of fan DC
• Kind of fan axial
• Supply voltage 12V DC
• Operating voltage 4.5...13.8V
• Fan dimensions 40x40x10mm
• Power consumption 1.05W
• Current rating 87mA
• Fan efficiency 16.73m3/h
• Noise level 31.4dBA
• Kind of Bearing Vapo
• Rotational rate/speed 8500rpm
• Weight 15.6g
• Min. insulation resistance 10MΩ
• Impeller material thermoplastic
• Enclosure material thermoplastic
• Insulation class A
• Leads 2 leads
• Operating temperature -10...70°C
• Static pressure 6.35mm H2O
• Cable length 300mm
• Fan motor brushless DC motor
• Flammability rating UL94V-0
• Wire size 28AWG
• Additional functions Autorestart Additional information
• Gross weight: 0.01 kg

Parametri

40x40x10mm
12VDC
uz ass
MagLev
16.73m3/st
31.4dBA
8500apgr.
15W

Papildu dokumentācija
