Apraksts

• Manufacturer: Infineon
• Product Category: MOSFET
• RoHS: Details
• Technology: Si
• Mounting Style: Through Hole
• Package/Case: TO-220-3
• Transistor Polarity: N-Channel
• Number of Channels: 1 Channel
• Vds - Drain-Source Breakdown Voltage: 200 V
• Id - Continuous Drain Current: 26 A
• Rds On - Drain-Source Resistance: 25 mOhms
• Vgs - Gate-Source Voltage: - 30 V, + 30 V
• Vgs th - Gate-Source Threshold Voltage: 1.8 V
• Qg - Gate Charge: 73 nC
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 150 C
• Pd - Power Dissipation: 46 W
• Channel Mode: Enhancement
• Packaging: Tube
• Brand: Infineon / IR
• Configuration: Single
• Fall Time: 29 ns
• Forward Transconductance - Min: 47 S
• Height: 15.65 mm
• Length: 10 mm
• Product Type: MOSFET
• Rise Time: 19 ns
• 2000
• Subcategory: MOSFETs
• Transistor Type: 1 N-Channel
• Typical Turn-Off Delay Time: 11 ns
• Typical Turn-On Delay Time: 17 ns
• Width: 4.4 mm
• Part # Aliases: IRFI4227PBF SP001564096
• Unit Weight: 2 g

Parametri

200V
47A
46W
0R052
TO-220F

Papildu dokumentācija
