Apraksts

• Manufacturer: Vishay
• Product Category: MOSFET
• RoHS: Details
• Technology: Si
• Mounting Style: Through Hole
• Package/Case: TO-247-3
• Transistor Polarity: N-Channel
• Number of Channels: 1 Channel
• Vds - Drain-Source Breakdown Voltage: 500 V
• Id - Continuous Drain Current: 20 A
• Rds On - Drain-Source Resistance: 270 mOhms
• Vgs - Gate-Source Voltage: - 20 V, + 20 V
• Vgs th - Gate-Source Threshold Voltage: 2 V
• Qg - Gate Charge: 120 nC
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 150 C
• Pd - Power Dissipation: 280 W
• Channel Mode: Enhancement
• Packaging: Tube
• Brand: Vishay Semiconductors
• Configuration: Single
• Fall Time: 43 ns
• Forward Transconductance - Min: 12 S
• Product Type: MOSFET
• Rise Time: 77 ns
• Series: IRFP
• 500
• Subcategory: MOSFETs
• Transistor Type: 1 N-Channel
• Typical Turn-Off Delay Time: 40 ns
• Typical Turn-On Delay Time: 18 ns
• Unit Weight: 6 g

Parametri

500V
20A
280W
0R27
TO-247
