Apraksts

• Specification
• Fan type DC
• Fan dimensions 40x40x10mm
• Bearing type Vapo
• Fans efficiency 11.9m3/h
• Noise level 27dBA
• Supply voltage 5V DC
• Power consumption 0.9W
• Operating voltage 3.5...6V
• Rotational rate/speed 5800rpm
• Weight 17g
• Rated current 0.18A
• Current and power consumption tolerance ±15%
• Min. insulation resistance 500MΩ;
• Fan material thermoplastic
• Enclosure material thermoplastic
• Insulation class A
• Operating temperature -10...70°C
• Static pressure 3.3mm H2O
• Leads 2 leads
• Flammability rating UL94V-0
• Fan motor brushless DC motor
• Cable length 300mm
• Wire size 26AWG
• Additional functions Autorestart

Parametri

40x40x10mm
5VDC
uz ass
MagLev
11.89m3/st
27dBA
5800apgr.
0.8W
