Apraksts

• Manufacturer: Analog Devices Inc.
• Product Category: Precision Amplifiers
• RoHS: Details
• Series: AD8551
• Number of Channels: 1 Channel
• GBP - Gain Bandwidth Product: 1.5 MHz
• SR - Slew Rate: 400 mV/us
• CMRR - Common Mode Rejection Ratio: 140 dB
• Output Current per Channel: 30 mA
• Ib - Input Bias Current: 50 pA
• Vos - Input Offset Voltage: 1 uV
• en - Input Voltage Noise Density: 42 nV/sqrt Hz
• Supply Voltage - Max: 5 V
• Supply Voltage - Min: 2.7 V
• Operating Supply Current: 1 mA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Shutdown: No Shutdown
• Mounting Style: SMD/SMT
• Package/Case: SOIC-8
• Packaging: Tube
• Brand: Analog Devices
• Height: 1.5 mm
• Input Voltage Range - Max: 5 V
• Length: 5 mm
• Operating Supply Voltage: 2.7 V to 5 V
• Product: Precision Amplifiers
• Product Type: Precision Amplifiers
• PSRR - Power Supply Rejection Ratio: 130 dB
