Apraksts

• Manufacturer SCHURTER
• Type of connector AC supply
• Connector plug
• Kind of connector female
• Current rating 10A
• Standard IEC 60320
• Connector variant C13 (F)
• Mechanical mounting for cable
• Electrical mounting screw terminal
• Operating temperature -25...70°C
• Spatial orientation right
• Information about relative position of each cable, terminals or PCB entry
• Max. wire diameter 8.5mm
• Rated voltage 250V AC
• Gross weight31.265 g

Parametri

Vadam
3
Ligzda
C13
