Apraksts

• Manufacturer AMASS
• Connector plug
• Type of connector DC supply
• Connector series AM-1009L
• Kind of connector male + female
• Number of pins 2
• Mechanical mounting for cable
• Electrical mounting soldered
• Contact plating gold flash
• Colour red
• Current rating 32A
• Flammability rating UL94V-0
• Operating temperature -20...120°C
• Rated voltage  500V
• Spatial orientation  straight
• Contact material brass
• Mechanical durability 1000 cycles
• Body material polyamide
• Wire size 12AWG
• Additional information
• Gross weight: 4.8 g
• Manufacturer part number: AM1009L

Parametri

500V
2
Ligzda/Spraudnis
Taisns
32A
AM1009L

Papildu dokumentācija
