Apraksts

• Manufacturer: Texas Instruments
• Product Category: Monostable Multi-vibrator
• RoHS: Details
• Elements per Chip: 2
• Logic Family: CD4000
• Logic Type: Monostable Multivibrator
• Package/Case: SOIC-Narrow-16
• Supply Current - Max: 0.1 mA
• Propagation Delay Time: 600 ns, 300 ns, 220 ns
• High Level Output Current: - 4.2 mA
• Low Level Output Current: 4.2 mA
• Supply Voltage - Max: 18 V
• Supply Voltage - Min: 3 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Packaging: Tube
• Brand: Texas Instruments
• Height: 1.58 mm
• Length: 9.9 mm
• Mounting Style: SMD/SMT
• Operating Supply Voltage: 3.3 V, 5 V, 9 V, 12 V
• Product Type: Monostable Multivibrator
• Series: CD14538B
• 40
• Subcategory: Logic ICs
• Width: 3.91 mm
• Unit Weight: 141,700 mg
