Apraksts

• Manufacturer: Texas Instruments
• Product Category: Multiplexer Switch ICs
• RoHS: Details
• Series: CD4097B
• Product: Multiplexers/Demultiplexers
• Mounting Style: Through Hole
• Package/Case: PDIP-24
• Number of Channels: 8 Channel
• Configuration: 2 x 8:1
• Supply Voltage - Min: 5 V
• Supply Voltage - Max: 18 V
• On Resistance - Max: 240 Ohms
• On Time - Max: 650 ns
• Off Time - Max: 440 ns
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Packaging: Tube
• Bandwidth: 20 Mhz
• Brand: Texas Instruments
• Height: 4.57 mm
• Length: 31.75 mm
• Operating Supply Voltage: 5 V to 18 V
• Pd - Power Dissipation: 500 mW (1/2 W)
• Product Type: Multiplexer Switch ICs
• Propagation Delay Time: 60 ns
