Apraksts

• Manufacturer HIRSCHMANN T&M
• Connector plug
• Type of connector fork terminals
• Current rating 30A
• Colour red
• Overall length 58.5mm
• Max cable section 2.5mm2
• Stud terminal maximal diameter 7mm
• Contact plating nickel plated
• Contact material brass
• Max. contact resistance: 1mΩ
• Operating temperature -25...40°C
• Connection screw terminal
• Mounting on cable
• Connector variant with 4mm transversal socket
• Rated voltage 60V DC
• Engineering PN 930584101

Parametri

Sarkana krasa
Uz vadu
Dakšas kontakts

Papildu dokumentācija
