Apraksts

• Manufacturer EATON/BUSSMANN
• Type of fuse fuse
• Current rating 5A
• Rated voltage 250V AC
• Fuse characteristics time-lag
• Kind of fuse ceramic, cylindrical, miniature
• Fuse size 5x20mm
• Manufacturer series S505
• Breaking capacity 1,5kA
• Breaking characteristics 1,5In: min 60min, 2,1In: max 30min, 2,75In: min 750ms, 2,75In: max 80s, 4In: min 150ms, 4In: max 5s, 10In: min 10ms, 10In: max 150ms
• Contact material brass
• Energy I2t 71,3A2s
• Resistance 13,1mΩ
• Kind of package bag
• Contact plating nickel plated
• Voltage drop 77,5mV
• Masa bruto1.058 g

Parametri

5A
250VAC
Lēns

Papildu dokumentācija
