Apraksts

• Manufacturer SCHURTER
• Type of fuse fuse
• Fuse characteristics time-lag
• Breaking capacity 100A
• Current rating 25A
• Rated voltage 32V AC/63V DC
• Mounting SMD
• Fuse size 3.2x1.6mm
• Max voltage drop 48mV
• Contact material copper
• Manufacturer series UST
• Energy I2t 220A2s
• Case 1206
• Fuses application Circuits with inrush
• Soldering temperature 245°C / 3 s
• Resistance 2.1mΩ
• Kind of package bag, tape
• Contact plating gold-plated, nickel plated
• Operating temperature -55...90°C
• Flammability rating UL94V-0

Parametri

25A
63VDC
Ātrs
