Apraksts

• Manufacturer BOURNS
• Type of encoder incremental
• Mounting THT
• Resolution 15imp/obrót
• Number of positions 30
• Output signal two phase A and B
• Mechanical durability 100000 cykli
• Operating voltage 5V DC
• Max. operating current 10mA
• Operating temperature -25...80°C
• Shaft surface D spring
• Shaft length 20mm
• Shaft diameter 6mm
• Cut depth 0,5mm
• Key stroke 1,5mm
• Encoders features with button
• Masa bruto4.25 g
