Apraksts

• Manufacturer: Infineon
• Product Category: Gate Drivers
• RoHS: Details
• Product: IGBT, MOSFET Gate Drivers
• Type: High-Side, Low-Side
• Mounting Style: SMD/SMT
• Package/Case: SOIC-16
• Number of Drivers: 2 Driver
• Number of Outputs: 2 Output
• Output Current: 3 A
• Supply Voltage - Min: 10 V
• Supply Voltage - Max: 20 V
• Rise Time: 20 ns
• Fall Time: 25 ns
• Minimum Operating Temperature: - 25 C
• Maximum Operating Temperature: + 125 C
• Series: IR(S)201X
• Packaging: Reel
• Packaging: Cut Tape
• Packaging: MouseReel
• Brand: Infineon Technologies
• Height: 2.35 mm
• Length: 10.5 mm
• Logic Type: CMOS, LSTTL
• Maximum Turn-Off Delay Time: 65 ns
• Maximum Turn-On Delay Time: 95 ns
• Moisture Sensitive: Yes
• Operating Supply Current: 230 uA
• Pd - Power Dissipation: 1.25 W
• Product Type: Gate Drivers
• Propagation Delay - Max: 135 ns
• Shutdown: Shutdown
• 1000
• Subcategory: PMIC - Power Management ICs
• Technology: Si
• Tradename: EiceDRIVER
• Width: 7.6 mm
• Part # Aliases: IR2010STRPBF SP001539676
• Unit Weight: 666 mg
