Apraksts

• Manufacturer: Infineon
• Product Category: Gate Drivers
• RoHS: Details
• Product: Driver ICs - Various
• Type: High-Side, Low-Side
• Mounting Style: SMD/SMT
• Package/Case: SOIC-8
• Number of Drivers: 2 Driver
• Number of Outputs: 2 Output
• Output Current: 1 A
• Supply Voltage - Min: 10 V
• Supply Voltage - Max: 20 V
• Rise Time: 35 ns
• Fall Time: 20 ns
• Minimum Operating Temperature: - 25 C
• Maximum Operating Temperature: + 125 C
• Series: IR(S)201X
• Packaging: Reel
• Packaging: Cut Tape
• Packaging: MouseReel
• Brand: Infineon Technologies
• Height: 1.5 mm
• Length: 5 mm
• Logic Type: CMOS, LSTTL
• Maximum Turn-Off Delay Time: 75 ns
• Maximum Turn-On Delay Time: 80 ns
• Moisture Sensitive: Yes
• Operating Supply Current: 230 uA
• Pd - Power Dissipation: 625 mW
• Product Type: Gate Drivers
• Propagation Delay - Max: 80 ns
• Shutdown: No Shutdown
• 2500
• Subcategory: PMIC - Power Management ICs
• Technology: Si
• Tradename: EiceDRIVER
• Width: 4 mm
• Part # Aliases: IR2011STRPBF SP001538080
• Unit Weight: 540 mg
