Apraksts

• Manufacturer LITTELFUSE
• Type of surge arrester surge arrester
• Mounting THT
• Leads axial
• Typical spark-over voltage 800V
• Max. overload voltage 1.5kV
• Min spark-over voltage 680V
• Surge arresters application audio, video input/output protection, data transmission systems protection, surge supression, telecommunication devices protection
• Min. insulation resistance 10GΩ
• Capacitance 1.5pF
• Impulse discharge current (8/20µs) 10kA
• Impulse discharge current AC 50Hz (1 s 10 times) 10A
• Body dimensions Ø8.1x6mm
• Max spark-over voltage 920V
• Operational life (10/1000µs, 500A) 400
• Series GDT
