Apraksts

• Manufacturer KEMET
• Type of capacitor polypropylene
• Capacitance 1.5nF
• Terminal pitch 15mm
• Tolerance ±5%
• Body dimensions 18x7.5x13.5mm
• Climate class 55/105/56 IEC 60068-1
• Operating temperature -55...105°C
• Pulse resistance 54kV/μs
• Mounting THT
• Series R73
• Lead length 30mm
• Alias 73UI11504000J
• Max. operating voltage 500V AC,  2kV DC
• Conform to the norm AEC-Q200
• Additional information
• Gross weight: 2.63 g
• Manufacturer part number: R73UI11504000J

Parametri

1.5nF
2000VDC
KEMET
500VAC
±5%
