Apraksts

• Manufacturer KEMET
• Type of capacitor polyester
• Capacitance 22nF
• Terminal pitch 5mm
• Tolerance ±10%
• Body dimensions 2.5x6.5x7.2mm
• Climate class 55/100/56 IEC 60068-1
• Operating temperature -55...105°C
• Pulse resistance 200V/μs
• Mounting THT
• Series R82
• Conform to the norm AEC-Q200
• Alias 82EC2220DQ50K
• Kind of package tape
• Max. operating voltage 63V AC,  100V DC
• Additional information
• Gross weight: 0.295 g
• Manufacturer part number: R82EC2220DQ50K

Parametri

22nF
63VDC
KEMET
40VAC
±10%

Papildu dokumentācija
