Apraksts

• Manufacturer WIMA
• Capacitor type polyester
• Capacitor application filtering, energy storage, decoupling
• Capacitance 680nF
• Max. operating voltage 1.5kV DC, 400V AC
• Terminal pitch 37.5mm
• Tolerance ±10%
• Body dimensions 20 x 39.5 x 41.5mm
• Operating temperature -55...100°C
• Capacitors series MKT
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 20V/μs
• Mounting THT
• Capacitance - µF 0.68µF

Parametri

680nF
1500VDC
WIMA
400VAC
±10%

Papildu dokumentācija
