Apraksts

• Manufacturer WIMA
• Type of capacitor polypropylene
• Capacitance 6.8nF
• Terminal pitch 10mm
• Tolerance ±10%
• Capacitor application high frequency circuits,  impulse circuits
• Body dimensions 4x9x13mm
• Climate class 55/100/56
• Operating temperature -55...100°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 1.2kV/μs
• Mounting THT
• Max. operating voltage 400V AC,  630V DC
• Kind of package tape
• Capacitors features
• low dielectric loss factor
• low ESR resistance value
• Additional information
• Gross weight: 0.838 g
• Manufacturer part number: MKP1J016803C00KI00

Parametri

6.8nF
630VDC
WIMA
400VAC
±10%
