Apraksts

• Manufacturer KEMET
• Type of capacitor polypropylene
• Kind of capacitor X1, Y2
• Manufacturer series R41
• Capacitance 22nF
• Operating voltage 1kV DC
• Max. operating voltage 300V AC
• Body dimensions 7.5x13.5x18mm
• Mounting THT
• Tolerance ±20%
• Terminal pitch 15mm
• Capacitor application between the supply pole and mass, between the supply poles
• Lead length 4mm
• Conform to the norm AEC-Q200
• Alias 413I222000M1M
• Operating temperature -40...110°C
• Climate class
• 40/100/56
• IEC 60068-1
• Gross weight1.625 g

Parametri

22nF
300VAC
