Apraksts

• Manufacturer: onsemi
• Product Category: Operational Amplifiers - Op Amps
• RoHS: Details
• Mounting Style: Through Hole
• Package/Case: DIP-8
• Number of Channels: 2 Channel
• Supply Voltage - Max: 28 V
• GBP - Gain Bandwidth Product: 350 kHz
• Output Current per Channel: 700 mA
• SR - Slew Rate: 1 V/us
• Vos - Input Offset Voltage: 60 mV
• Supply Voltage - Min: 4 V
• Minimum Operating Temperature: - 25 C
• Maximum Operating Temperature: + 85 C
• Ib - Input Bias Current: 2.5 uA
• Operating Supply Current: 12 mA
• Shutdown: Shutdown
• CMRR - Common Mode Rejection Ratio: 60 dB
• Series: L272
• Packaging: Tube
• Amplifier Type: Power Amplifier
• Height: 3.4 mm
• Length: 9.2 mm
• Product: Operational Amplifiers
• Supply Type: Single, Dual
• Width: 6.4 mm
• Brand: onsemi / Fairchild
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
• Maximum Dual Supply Voltage: +/- 14 V
• Minimum Dual Supply Voltage: +/- 2 V
• Operating Supply Voltage: 4 V to 28 V, +/- 2 V to +/- 14 V
• Pd - Power Dissipation: 1000 mW
• Product Type: Op Amps - Operational Amplifiers
• PSRR - Power Supply Rejection Ratio: 54 dB
• Factory Pack Quantity: 3000
• Subcategory: Amplifier ICs
• Voltage Gain dB: 75 dB
• Unit Weight: 851 mg
