Apraksts

• Manufacturer: Texas Instruments
• Product Category: Timers & Support Products
• RoHS: Details
• Series: LMC555
• Type: Standard
• Number of Internal Timers: 1 Timer
• Supply Voltage - Max: 15 V
• Supply Voltage - Min: 1.5 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: Through Hole
• Package/Case: PDIP-8
• Packaging: Tube
• Brand: Texas Instruments
• Height: 3.3 mm
• High Level Output Current: 50 mA
• Length: 9.27 mm
• Low Level Output Current: - 10 mA
• Operating Supply Current: 50 uA
• Pd - Power Dissipation: 1126 mW
• Product Type: Timers & Support Products
• Propagation Delay - Max: 100 ns (Typ)
