Apraksts

• Manufacturer CANAL ELECTRONIC
• Type of switch microswitch SNAP ACTION
• Switches features with lever with roller simulation
• Contacts configuration  SPDT
• AC contacts rating @R  1A / 125V AC
• Max. contact resistance: 50mΩ
• Switching method  ON-(ON)
• Number of positions 2
• Stable positions number 1
• IP rating IP40
• Leads for PCB,  straight
• Body dimensions 12.8x5.8x6.5mm
• Mechanical durability 1000000 cycles
• Operating temperature -25...65°C
• Operating Force 0.7N
• Lever length 14mm
• Electrical life 30000 cycles
• Terminal pitch 5.08mm
• Terminals plating silver plated
• Contact material silver alloy
• Terminals material nickel
• Additional information
• Gross weight: 0.67 g
• Manufacturer part number: DM-102P-110

Parametri

SPDT
ON-(ON)
IP40
Ar sviru
13x5.8x6.5mm
1A/125VAC

Papildu dokumentācija
