Apraksts

• Manufacturer OMRON
• Switch type microswitch
• Switches features with lever
• Contacts configuration SPDT
• AC contacts rating
• (at resistance load) 0.1 A / 125 VAC
• DC contacts rating
• (at resistance load) 2 A / 12 VDC
• Switching method ON-(ON)
• Stable positions number 1-position
• Sealing IP67
• Leads for PCB
• Body dimensions 13.3 x 5.3 x 6.5mm
• Mechanical durability 1000000cycles
• Operating temperature -40...85°C
• Switching torque 0.75N
• Lever length 13mm
• Electrical life 100000cycles
• Max. contact resistance: 100mΩ
• Contact plating gold plated
• Terminal pitch 5.08mm

Parametri

SPDT
0.1A/125VAC
2A/12VDC
ON-(ON)
IP67
ar sviru
13.3x5.3x6.5mm

Papildu dokumentācija
