Apraksts

• Manufacturer OMRON
• Manufacturer series VX
• Type of switch microswitch SNAP ACTION
• Switches features without lever
• Contacts configuration SPDT
• AC contacts rating @R
• (at resistance load) 5A / 250VAC
• Switching method
• (item in brackets is instantaneous) ON-(ON)
• Number of positions 2
• Stable positions number 1-position
• IP rating IP40
• Leads for soldering
• Body dimensions 27.8 x 10.3 x 15.9mm
• Mechanical durability 50000000cycles
• Operating temperature -25...80°C
• Operating Force 0.25N
• Electrical life 500000cycles
• Max. contact resistance: 30mΩ

Parametri

SPDT
5A/250VAC
ON-(ON)
IP40
Bez sviras
27.8x10.3x15.9mm

Papildu dokumentācija
