• Manufacturer GOLDTOOL
• Type of meter AC digital clamp meter
• Max. diameter of measured cable 12mm
• Kind of display used LCD 3,75 digit (3999), with a backlit
• Sampling 2,5x/s
• AC current measuring range 0,1...200A
• AC current measuring accuracy ±(3% + 3 digits)
• DC voltage measuring range 0,001...4/40/400/1000V
• DC voltage measuring accuracy ±(0,7% + 1 digit)
• AC voltage measuring range 0,001...4/40/400/700V
• AC voltage measuring accuracy ±(0,8% + 5 digits)
• Resistance measuring range 0,1...400/4k/40k/400k/4M/40MΩ
• Resistance measuring accuracy ±(1,2% + 4 digits)
• Capacitance measuring range 10p...40n/400n/4µ/40µF
• Capacitance measuring accuracy ±(4% + 10 digits)
• Frequency measuring range 0,01...40/400/4k/40k/100kHz
• Frequency measuring accuracy ±(2% + 1 digit)
• Duty cycle factor 0.1...99.9%
• Diode test yes
• Continuity test acoustic signal for R<30Ω
• Pollution degree 2
• Dimensions 192x68x43mm
• Weight without batteries 272g
• Power supply 1 battery 9V 6F22
• Measurement frequency, AC voltage, DC voltage, capacitance, AC current, resistance
• Conform to the norm EN61010 600V CAT III Measuring instrument features:
• auto and manual ranging
• automatic power-off
• HOLD function
• REL function
• easy current measurement due to open-jaw technology
• low battery indicator
• Standard equipment:
• soft cover with strap
• test leads
• Additional information
• Gross weight: 0.6 kg
