Apraksts

• Manufacturer UNI-T
• Type of meter AC digital clamp meter
• Max. diameter of measured cable 26mm
• Kind of display used LCD (1999)
• AC current measuring range 20/200/600A
• AC current measuring accuracy ±(1,5% + 5 digits)
• DC voltage measuring range 0,1m...200m/2/20/200/600V
• DC voltage measuring accuracy ±(0,8% + 1 digit)
• AC voltage measuring range 1m...2/20/200/600V
• AC voltage measuring accuracy ±(1,2% + 5 digits)
• Resistance measuring range 100m...200/2k/20k/200k/2M/20MΩ
• Resistance measuring accuracy ±(1% + 2 digits)
• Diode test yes
• Continuity test acoustic signal for R<10Ω
• Pollution degree 2
• Dimensions 210x75.6x30mm
• Weight with battery 220g
• Power supply 1 battery 9V 6F22
• Measurement AC current, AC voltage, continuity, DC voltage, resistance
• Conform to the norm EN61010 300V CAT III, EN61010 600V CAT II Measuring instrument features:
• automatic power-off
• autoranging
• HOLD function
• low battery indicator
• MAX function
• overflow indication
• polarization indicator
• Standard equipment:
• batteries
• test leads
• Additional information
• Gross weight: 443.3 g
