• Manufacturer UNI-T
• Type of meter digital multimeter
• Interface RS232
• Measurement AC current,  DC current,  resistance,  temperature
• Kind of display used LCD,  with a backlit
• DC voltage measuring range 0.1...400mV/4V/40V/400V/1kV
• DC voltage measuring accuracy ±(0,8% + 1 digit)
• AC voltage measuring range 1mV...4V/40V/400V/750V
• AC voltage measuring accuracy ±(1% + 5 digits)
• Bandwidth for AC voltage measurements 40...400Hz
• DC current measuring range 0.1...400µA/4mA/40mA/400mA/4A/10A
• AC current measuring range  0.1...400µA/4000µA/40mA/400mA/4A/10A
• (1) indirect measurement)
• DC current measuring accuracy ±(1,2% + 3 digits)
• AC current measuring accuracy ±(2% + 5 digits)
• Bandwidth for AC current measurements 40...400Hz
• Resistance measuring range 100mΩ...400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
• Resistance measuring accuracy ±(1% + 2 digits)
• Capacitance measuring range 10pF...40nF/400nF/4µF/40µF/100µF
• Capacitance measuring accuracy ±(3% + 5 digits)
• Frequency measuring range 10...10MHz
• Frequency measuring accuracy ±(0,1% + 3 digits)
• Temperature measuring range -40...1000°C
• Temperature measurement accuracy ±(1% + 3 digits)
• Temperature measurement resolution 1°C
• Duty cycle factor 0.1...99.9%
• Test diodes
• Continuity test acoustic indication
• Weight with battery 300g
• Conform to the norm EN61010 600V CAT IV,  EN61010 1000V CAT III
• Dimensions (W x H x D) 85x177x40mm
• Power supply
• battery 6F22 9V x1
• Standard equipment
• drop-like K-type temperature probe
• test leads
• Measuring instrument features
• auto and manual ranging
• automatic power-off
• HOLD function
• low battery indicator
• REL function
• Additional information
• Gross weight: 532.351 g
• Guarantee (months): 12
• Manufacturer part number: UT60C
