Apraksts

• Specification
• Connector type wire-wire
• Connector plug
• Connector type male/female
• Number of pins 3
• Connector variant w/o terminals
• Mounting on cable
• Operating temperature -25...85°C
• Flammability rating UL94V-2
• Contacts pitch 6.35mm
• Type of pin configuration 1x3
• Rated voltage 600V
• Enclosure material polyamide
• Connector series NLS
• Locking system lock
• Connectors features designed for any type of contacts

Parametri

6.35mm
1x3
3
Taisns
Uz vadu
NLS
Spraudnis

Papildu dokumentācija
