GDS-1052-U Oscilografs ciparu, 2 kanali, 50MHz, Pēc iepriekšēja pasūtījuma

* Produktu fotogrāfijas ir tikai noskatīšanai un var dažreiz atšķirties no priekšmeta reāla izskata. Bet galvenās īpašības ir vienādas.

GDS-1052-U Oscilografs ciparu, 2 kanali, 50MHz, Pēc iepriekšēja pasūtījuma

Cena: 427.10 €
00025972
GDS-1052-U
0
  • Apraksts

    • Manufacturer GW INSTEK
    • Type of oscilloscope digital
    • Band ≤50MHz
    • Number of channels 2
    • Memory record length 4kpts/ch
    • Sampling 250Msps (in real time), 25Gsps (in equivalent time)
    • Rise time ≤7ns
    • Kind of display used LCD TFT 5,7" (320x234), color
    • Time base 1n...50s/div
    • Trigger modes automatic, normal, single
    • Max. input voltage 300V
    • Input impedance 1MΩ/16pF
    • Input coupling AC, DC, GND
    • Dimensions 310 x 142 x 140mm
    • Weight 2.5kg
    • Power supply 100...240VAC, 48...63Hz
    • Interface USB
    • Trigger video signal, impulse width, rising edge, falling edge
    • Plug variant EU Measuring instrument features:
    • AUTOSET function for setting display parameters (time base, gain)
    • 15 runs memory
    • memory for 15 settings
    • X-Y, ROLL, MAIN operation mode
    • automatic measurement of many parameters
    • mathematical functions: addition, subtraction and FFT
    • Standard equipment:
    • mains cable
    • software
    • oscilloscope probe with 1:1/10:1 divider
    • Kind of output connector:
    • USB A socket
    • USB B socket
    • Additional information
    • Gross weight: 3.7 kg
    • Guarantee (months): 24
