Apraksts

• Specification
• Switch type rotary
• Stable positions number 2-position
• Contacts configuration NC + NO
• AC contacts rating
• (at resistance load) 3 A / 230 VAC
• Switch standard 22mm
• Actuator colour black
• Illumination none
• Sealing IP65
• Button shape prominent
• Operating temperature -20...60°C
• Mounting hole diameter Ø;22.5mm
• Number of positions 2
• Button marking blank
• Associated items B-1-C, B-1-O

Parametri

3A/230VAC
NC + NO
2
IP65
2
Paneļu slēdzis
Ar fiksāciju
Melns
Ø22mm
