Apraksts

• Manufacturer AUSPICIOUS
• Type of switch push-button
• Contacts configuration  NC + NO
• AC contacts rating @R  3A / 230V AC
• Switch standard 22mm
• Actuator colour green
• Illumination BA9S,  filament lamp
• IP rating IP65
• Button shape flat
• Number of positions 2
• Mounting hole diameter Ø22.5mm
• Manufacturer series LBF22
• Operating temperature -20...60°C
• Button marking blank
• Related items LN-B9/110AC/G,  LN-B9/230AC/G,  S-9LL230AC-G,  S-9LL230AC-R,  S-9LL24-G,  S-9LL24-R
• Stable positions number 1
• Caution!
• Bulb has to be ordered separately
• Additional information
• Gross weight: 47.2 g
• Manufacturer part number: LBF22-1O/C G, W/O LAMP

Parametri

3A/230VAC
NC + NO
2
IP65
1
Paneļu slēdzis
Bez fiksācijas
Zaļš
Ø22mm

Papildu dokumentācija
