Apraksts

• Manufacturer ONPOW
• Type of switch push-button
• Number of all positions 2
• Stable positions number 1-position
• Contacts configuration SPDT
• AC contacts rating @R
• (at resistance load) 3A / 250VAC
• DC contacts rating @R
• (at resistance load) 2A / 24VDC
• Actuator colour red
• Illumination LED 24V AC/DC
• Backlight colour red
• Leads for soldering
• Switching method
• (item in brackets is instantaneous) ON-(ON)
• Operating temperature -25...55°C
• Mounting on panel
• Mounting hole diameter Ø16mm
• Button shape square
• Body colour black
• IP rating IP40

Parametri

3A/250VAC
2A/24VDC
ON-(ON)
2
IP40
1
Paneļu slēdzis
Bez fiksācijas
Sarkans
Ø16mm

Papildu dokumentācija
