Apraksts

• Manufacturer E-SWITCH
• Type of switch push-button
• Number of positions 2
• Contacts configuration 6PDT
• DC contacts rating @R(at resistive load) 0.1A / 30V DC
• Switching method(the position in bracket indicates momentary position.) ON-ON
• Leads angled, for PCB
• Operating temperature -20...70°C
• Electrical life 10000 cycles
• Max. contact resistance: 100mΩ
• Operating Force 3.73N
• Mechanical durability 30000 cycles
• Button shape prominent, square
• Contact plating silver plated
• Mounting THT
• Body dimensions 7.3x7x29.7mm
• Button height(measured from PCB) 10.8mm
• Stable positions number 2
• Gross weight2.4 g

Parametri

6PDT
0.1A/30VDC
ON-ON
Poga
Ar fiksāciju
Bez vītnes
Bez apgaismojuma
