Apraksts

• Manufacturer OMRON
• Type of relay electromagnetic
• Contacts configuration 4PDT
• Rated coil voltage 120V AC
• AC contacts rating @R
• (at resistive load) 5A / 220V AC
• DC contacts rating @R
• (at resistive load) 5A / 24V DC
• Contact current max. 5A
• Switched voltage max. 125V DC, max. 250V AC
• Relay variant industrial
• Mounting socket
• Coil voltage min. 96V AC
• Relay series MY4
• Operating temperature -55...70°C
• Body dimensions 28x21.5x36mm
• Coil resistance 4.43kΩ
• Mechanical durability 50000000 cycles
• Operate time 20ms
• Release time 20ms
• Coil current 10.8mA
• Contact resistance 100mΩ
• Coil power consumption 1.2VA
• Leads 2,5x0,5mm connectors
• Related items PY14-02, PYF14A-E

Parametri

OMRON
4PDT
4x5A/250VAC
4x5A/24VDC
uz pārslēgšanu
monostabilais
4
110VAC

Papildu dokumentācija
