Apraksts

• Specification
• Relay type electromagnetic
• Contacts configuration SPDT x2
• Rated coil voltage 12V DC
• DC contacts rating
• (at resistance load) 25 A / 14 VDC
• Contact current max. 35A
• Switched voltage max 16V DC
• Relay variant miniature
• Mounting PCB
• Coil resistance 240Ω;
• Operate time 10ms
• Body dimensions 24 x 16.2 x 14.1mm
• Release time 5ms
• Operating temperature -40...85°C
• Relay series FBR512
• Contact material AgSnInO
• Contacts pitch 5mm
• Coil current 50mA

Parametri

FUJITSU
12VDC
SPDTx2
25A/14VDC
uz pārslēgšanu
monostabilais
2
2

Papildu dokumentācija
