Apraksts

• Manufacturer FUJITSU
• Type of relay electromagnetic
• Contacts configuration DPDT
• Contacts configuration
• Rated coil voltage 12V DC
• Contact current max. 2A
• AC contacts rating @R(at resistive load) 0,5A / 125V AC
• at resistive load
• DC contacts rating @R(at resistive load) 1A / 30V DC
• at resistive load
• Switched voltage max. 220V DC, max. 250V AC
• Relay variant subminiature
• Mounting PCB
• Coil resistance 1,44kΩ
• Coil voltage min. 9V DC
• Operate time 6ms
• Release time 6ms
• Coil power consumption 100mW
• Operating temperature -40...85°C
• Relay series NA
• Contact material AgPd/Au 0,2μm
• Terminal pitch 2,54mm
• Additional information
• Gross weight: 1.718 g

Parametri

FUJITSU
12VDC
DPDT
0.5A/125VAC
1A/30VDC
uz pārslēgšanu
2
1
bistabilais

Papildu dokumentācija
