Apraksts

• Manufacturer OMRON OCB
• Type of relay electromagnetic
• Contacts configuration  DPDT
• Rated coil voltage 12V DC
• AC contacts rating @R  0.5A / 125V AC
• DC contacts rating @R  2A / 30V DC
• Contact current max. 2A
• Switched voltage max. 125V AC,  max. 125V DC
• Relay variant miniature
• Mounting PCB
• Coil resistance 288Ω
• Operate time 7ms
• Body dimensions 20.5x10.1x11.5mm
• Release time 3ms
• Coil power consumption 500mW
• Operating temperature -25...70°C
• Relay series G5V-2
• Contact resistance 50mΩ
• Terminal pitch 5mm
• Coil current 41.7mA
• Contact plating gold-plated
• Papildu informācijas
• Masa bruto: 5.2 g
• Oriģināls simbols: G5V-2 12VDC

Parametri

OMRON
12VDC
DPDT
2x0.5A/125VAC
2A/30VDC
uz pārslēgšanu
2
monostabilais
1

Papildu dokumentācija
