Apraksts

• Specification
• Relay type electromagnetic
• Contacts configuration SPST-NO
• Rated coil voltage 12V DC
• AC contacts rating
• (at resistance load) 5 A / 250 VAC
• DC contacts rating
• (at resistance load) 5 A / 30 VDC
• Contact current max. 5A
• Switched voltage max 30V DC, max 250V AC
• Relay variant miniature
• Mounting PCB, socket
• Body dimensions 17.5 x 6.5 x 12.5mm
• Mechanical durability 20000000cycles
• Operating temperature -20...70°C
• Weight 3g
• Relay series G6D
• Contact resistance 100mΩ;
• Electrical life 100000cycles
• Contacts pitch 5mm

Parametri

OMRON
12VDC
SPST-NO
5A/250VAC
5A/30VDC
uz saslēgšanu
monostabilais
1
1
