Apraksts

• Manufacturer TE Connectivity
• Type of relay electromagnetic
• Contacts configuration DPDT
• Rated coil voltage 230V AC
• AC contacts rating @R
• (at resistive load) 12A / 250V AC
• DC contacts rating @R
• (at resistive load) 12A / 30V DC
• Contact current max. 12A
• Switched voltage max. 300V DC, max. 400V AC
• Relay variant industrial
• Mounting socket
• Relay series PT
• Operating temperature -40...70°C
• Body dimensions 28x22.5x30mm
• Coil resistance 19465Ω
• Contact material AgNi
• Coil power consumption 1VA
• Leads 2,8x0,5mm connectors
• Optional equipment test button with blocking function
• Related items PT78720
• Additional information
• Gross weight: 26.09 g
• Manufacturer part number: 5-1419111-1

Parametri

TE Connectivity
230VAC
DPDT
2x12A/250VAC
12A/30VDC
uz pārslēgšanu
monostabilais
2

Papildu dokumentācija
