Apraksts

• Manufacturer FINDER
• Type of relay electromagnetic
• Contacts configuration  SPDT
• Rated coil voltage 230V AC
• AC contacts rating @R  16A / 250V AC
• DC contacts rating @R  16A / 30V DC
• Contact current max. 30A
• Switched voltage max. 220V DC,  max. 400V AC
• Relay variant miniature
• Mounting PCB,  socket
• Coil resistance 28kΩ
• Body dimensions 29x12.4x25mm
• Coil power consumption 1.2VA
• Operating temperature -40...85°C
• Relay series 40.61
• Contact material AgCdO
• Terminal pitch 5mm
• Coil current 5mA
• Additional information
• Gross weight: 16.735 g
• Manufacturer part number: 40.61.8.230.0000

Parametri

FINDER
230VAC
SPDT
16A/250VAC
16A/30VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
