Apraksts

• Manufacturer TE Connectivity
• Type of relay electromagnetic
• Contacts configuration DPDT
• Rated coil voltage 24V DC
• Contact current max. 8A
• AC contacts rating @R(at resistive load) 8A / 250V AC
• DC contacts rating @R(at resistive load) 8A / 30V DC
• Switched voltage max. 300V DC, max. 400V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 1.44kΩ
• Coil voltage min. 16.8V DC
• Operate time 7ms
• Body dimensions 29x12.7x15.7mm
• Release time 2ms
• Coil power consumption 400mW
• IP rating IP40
• Operating temperature -40...70°C
• Relay series RT2
• Contact material AgNi 90/10 Au
• Terminal pitch 5mm
• Height 15.7mm
• Number of pins 8

Parametri

TE Connectivity
DC24V
DPDT
2x8A/250VAC
2x8A/30VDC
uz pārslēgšanu
monostabilais
2
