Apraksts

• Specification
• Relay type electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 24V DC
• AC contacts rating
• (at resistance load) 0.5 A / 125 VAC
• DC contacts rating
• (at resistance load) 1 A / 24 VDC
• Contact current max. 1A
• Switched voltage max 125V AC, max 60V DC
• Relay variant subminiature
• Mounting PCB
• Coil resistance 3.84kΩ;
• Coil voltage min. 16.8V DC
• Body dimensions 12.5 x 7.5 x 10mm
• Coil power consumption 150mW
• Operating temperature -30...70°C
• Relay series G5V-1
• Contact resistance 100mΩ;
• Contacts pitch 2.54mm
• Coil current 6.25mA
• Terminal pitch 2.54mm

Parametri

OMRON
DC24V
SPDT
0.5A/125VAC
1A/24VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
