Apraksts

• Manufacturer TE Connectivity
• Type of relay electromagnetic
• Contacts configuration  SPDT
• Rated coil voltage 24V DC
• AC contacts rating @R  10A / 250V AC
• Contact current max. 10A
• Switched voltage max. 400V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 1.6kΩ
• Operate time 10ms
• Body dimensions 20x15x15mm
• Release time 20ms
• Coil power consumption 360mW
• Mechanical durability 30000 cycles
• Operating temperature -40...85°C
• Weight 5.4g
• Relay series PB
• Contact material AgNi 90/10
• Additional information
• Gross weight: 5.867 g
• Manufacturer part number: 9-1415029-1

Parametri

TE Connectivity
DC24V
SPDT
10A/250VAC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
