Apraksts

• Manufacturer SHORI ELECTRIC
• Type of relay electromagnetic
• Contacts configuration  SPDT
• Rated coil voltage 24V DC
• Contact current max. 20A
• Relay series S12
• Relay variant power
• Operating temperature -30...85°C
• Mounting PCB
• Coil resistance 660Ω
• Body dimensions 19.5x26.8x31.9mm
• Coil power consumption 930mW
• Contact resistance 50mΩ
• Leads terminal PCB
• Operate time 15ms
• Release time 10ms
• Contact material silver alloy
• Mechanical durability 10000000 cycles
• Coil current 36mA
• Weight 25g
• Electrical life 10000 cycles
• Dimensions see
• Output configuration see
• Additional information
• Gross weight: 25.56 g
• Manufacturer part number: S12-PCS-24

Parametri

DC24V
SPDT
20A/250VAC
20A/28VDC
uz pārslēgšanu
monostabilais
1
SHORI ELECTRIC

Papildu dokumentācija
