Apraksts

• Manufacturer RAYEX ELECTRONICS
• Type of relay electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 24V DC
• Contact current max. 30A
• Relay series L90
• Relay variant open frame, power
• Operating temperature -55...85°C
• Mounting PCB
• Coil resistance 660Ω
• Coil power consumption 900mW
• Switched voltage max 30V DC, max 240V AC
• Contact resistance 50mΩ
• AC contacts rating @R
• (at resistance load) 30A / 240V AC
• DC contacts rating @R
• (at resistance load) 20A / 30V DC
• Leads for PCB
• Operate time 15ms
• Release time 15ms
• Contact material AgCdO
• Mechanical durability 10000000cycles
• Electrical life 100000cycles

Parametri

RAYEX ELECTRONICS
DC24V
SPDT
30A/240VAC
20A/30VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
